Type

2-way active enclosure

Powering and driving system

LA4X, LA8, LA12X

Nominal frequency(-10dB)

70Hz - 20kHz ([KIVA II] preset)

Maximum SPL

138dB ([KIVA II] preset)

Available setting

H x V: 100° x 15° 4

Transducers

LF: 2 × 6.5’’, bass reflex

HF: 1 x 1.75’’ compression

Rigging

Steel, certified for: 12 KARAi (BGV-C1 compliant)

Angle increments: 0, 1, 2, 3, 4, 5, 7.5, 10°

Dimension(W×H×D)

520 x 175/104 x 357mm

20.5 x 6.9/4.1 x 14in

Net weight

13kg - 28.6lbs.
