PRODUCTS

Type

2-way-passive enclosure

Powering and driving system

LA4X, LA8, LA12X

Bandwidth

87 Hz - 20 kHz ([SYVA] preset)

Maximum SPL

137 dB ([SYVA] preset)

Nominal directivity

H x V: 140° x (+5°/-21°)

Transducers

LF: 1 × 12’’, bass reflex

HF: 1 × 3’’compression

Rigging

DIN580 - compatible M8 threaded insert for secondary safety

2 integrated inserts for rigging accessory

Dimension(W×H×D)

144 x 1304 x 209 mm

5.7 x 51.3 x 8.2 in

Net weight

21 kg / 46 lb
